Zon op 9 maart 2022 met AR2960

Activity Forums Astrofotografie Zonnestelsel Zon op 9 maart 2022 met AR2960

Viewing 5 posts - 1 through 5 (of 5 total)
  • Author
    Posts
  • #26536
    InFINNityDeck
    Participant

    Vandaag ook maar weer eens met de C11 EdgeHD naar de Zon gekeken. Visueel was het onwijs, dus snel de camera erachter gemonteerd om te kijken of dat ook vast te leggen was. De scintillation monitor gaf een seeing van ruim onder de 2″, dus dat moest wel goed gaan. Er stond echter behoorlijk wat wind en dat gooide weer wat roet in het eten. Evengoed een aardige opname op f/20, gebruik maken van ND5.0 folie en Baader Continuum filter.

    Stack van de 10 beste beeldjes uit een serie van 1998. Belichting circa 6ms bij gain van 300. Opname met FireCapture, verwerking in AutoStakkert!3, PSP (Unsharp Mask), IMPPG (Lucy-Richardson Deconvolutie) en nogmaals PSP (colorize, sharpening).

    Opname met de C11 op 14:06UTC gemaakt en ter vergelijking een opname met de SkyWatcher Esprit met ND5.0 filter en ZWO ASI1600MM Pro Cool van 09:11UTC (AR2960 is in het midden te zien).

    Nicolàs

    https://www.dehilster.info/astronomy

    In the observatory: Mount: 10Micron GM3000HPS, OTAs mounted: SW Esprit 80ED & Esprit 150ED, Celestron C11 XLT EdgeHD, Lunt LS80THA single stack, GTT60 (60mm aperture Galilean Type Telescope), Cameras: ZWO ASI1600MM Cool (2x), ASI174MM, ASI290MM & MC, QHYCCD QHY163M, OTAs on the ground: SW Explorer 300PDS, Bresser Messier 130/650 & 90/500.

    #26537
    Musquetier
    Participant

    Wauw, wat een detail. Maar hoezo heb je last van de wind? Haal je dat er niet uit tijdens het stacken?

    #26538
    InFINNityDeck
    Participant

    Door de wind trilt het beeld, deels doordat de kijkers wind vangen, deels doordat de lucht snel verandert. Er vindt daardoor toch wat versmering plaats, mede door de wat lange sluitertijd van ruim 6ms. Eigenlijk moet ik ND3.8 filter gebruiken, dat laat circa 16x zoveel licht door, waardoor de belichtingstijden ruim onder de 1 ms zakken (zou bij deze opname circa 0.4ms zijn). Helaas is dat folie er niet meer op C11-formaat. Baader zegt hierover:

    Please note: At this time AstroSolar PHOTO-Film in density 3.8 is only available in sheets of 200×290 mm. Other sizes are not available – and it must be said that we are VERY reluctant to keep offering this material in larger size because it is really dangerous – when misused.

    Throughout the 21 years that we offer AstroSolar Film, safety laws have tightened considerably and while our AstroSolarFilm at OD5.0 will fill all safety requirements for telescope observation even with very large apertures of 1 meter in diameter, PHOTO Film could cause eye damage when someone would wrongly use it for visual observation despite all our warnings. The juridical consequences are simply not forseeable – if anyone would use the material for visual observation and burn his retina in spite of all warnings and protective advice given.

    Actually – AstroSolar Photo Film OD 3.8 cannot at all be used for visual observation of the sun, not even with additional filters. It is solely suitable for high quality, short exposure time digital imaging, when using eyepieces or barlow lenses as projection device for achieving very long focal lengths. Alternatively suitable – even w/o any barlow focal length extention – will be the latest generation of lucky-imaging video-cameras, featuring pixel sizes of around 2 micron.

    In a time were you can be sued $ 200 Mio in the US for selling microwave ovens that the owner is so … to be frying his cat with – it is very easy to imagine what might happen if people refuse to obey all warnings and get injured because of staring into the sun with equipment not intended to. We do ask for understanding that we cannot risk to experience such a situation anymore. We do ask everyone to extend greatest care when producing his own PhotoSolar-Filter. This material is not intended for the casual observer or imager but for specialists.

    Dus is het modderen met 5.0 en hopen op rustig weer met een hoge transparantie en lage onrust in de atmosfeer.

    Nicolàs

    https://www.dehilster.info/astronomy

    In the observatory: Mount: 10Micron GM3000HPS, OTAs mounted: SW Esprit 80ED & Esprit 150ED, Celestron C11 XLT EdgeHD, Lunt LS80THA single stack, GTT60 (60mm aperture Galilean Type Telescope), Cameras: ZWO ASI1600MM Cool (2x), ASI174MM, ASI290MM & MC, QHYCCD QHY163M, OTAs on the ground: SW Explorer 300PDS, Bresser Messier 130/650 & 90/500.

    #26539
    InFINNityDeck
    Participant

    Hierbij de originele video om een idee te geven hoe het beeld eruit ziet tijdens de opname:

    Nicolàs

    https://www.dehilster.info/astronomy

    In the observatory: Mount: 10Micron GM3000HPS, OTAs mounted: SW Esprit 80ED & Esprit 150ED, Celestron C11 XLT EdgeHD, Lunt LS80THA single stack, GTT60 (60mm aperture Galilean Type Telescope), Cameras: ZWO ASI1600MM Cool (2x), ASI174MM, ASI290MM & MC, QHYCCD QHY163M, OTAs on the ground: SW Explorer 300PDS, Bresser Messier 130/650 & 90/500.

    #26540
    Volman
    Participant

    Echte een mooi plaatje geworden, maar die wind vind ik nog wel meevallen. Bij mij zijn de filmpje vaak meer bewogen door de wind dan in jou voorbeeld. Met Stacken zou dat goed ondervangen kunnen worden.

    Paul
